FLIGHT OVERLAY (P/N 17174-001) - As Removed
P/N: 17174-001
Category: Lighting
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| As Removed | 1 Available |
Product Description
The 17174-001 is a flight overlay for integrally illuminated cockpit panels. This transparent or translucent component sits atop backlit switch and annunciator assemblies, protecting printed legends while allowing light transmission through labeled markings. The overlay conforms to MIL-DTL-7788 and SAE AS7788 standards for aircraft lighting applications.
Installation requires verification of fit per the aircraft maintenance manual or control panel component maintenance documentation. Used on flight decks across corporate and commercial aircraft where backlighting illuminates control markings during night operations.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the FLIGHT OVERLAY (P/N 17174-001)?
The 17174-001 is a flight overlay for integrally illuminated cockpit panels. This transparent or translucent component sits atop backlit switch and annunciator assemblies, protecting printed legends while allowing light transmission through labeled markings.
Is the 17174-001 a PMA or OEM part?
The FLIGHT OVERLAY may be available as an OEM (Original Equipment Manufacturer) or PMA (Parts Manufacturer Approval) part depending on condition and source. Both carry FAA certification for airworthiness. Currently available in: As Removed. Contact us for sourcing details.
Does the 17174-001 include installation hardware?
Installation hardware requirements vary by application. Check your aircraft's Structural Repair Manual (SRM) or Illustrated Parts Catalog (IPC) for the complete installation kit requirements for the FLIGHT OVERLAY. We stock related hardware and can help identify companion parts.
Can the 17174-001 be shipped internationally?
Yes, we ship airframe components worldwide. International orders typically arrive within 3-14 business days depending on destination. Export documentation and customs forms are included. Contact us for international shipping quotes on the 17174-001.
