DIODE (P/N 1n1201) - New Surplus
P/N: 1n1201
Category: Electrical Components
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| New Surplus | 3 Available |
Product Description
The 1N1201 is a stud-mount rectifier diode in a DO-4 package for aircraft electrical systems. This semiconductor component suppresses inductive voltage spikes across relay and contactor coils in 14/28-V DC power distribution circuits. It also performs general rectification duties in avionics and control system applications.
The diode follows JEDEC 1N numbering standards, with JAN variants meeting MIL-PRF-19500 specifications. Installation requires torquing the stud mount per aircraft maintenance manual requirements and wiring diagram specifications.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the DIODE (P/N 1n1201)?
The 1N1201 is a stud-mount rectifier diode in a DO-4 package for aircraft electrical systems. This semiconductor component suppresses inductive voltage spikes across relay and contactor coils in 14/28-V DC power distribution circuits.
Is the 1n1201 compatible with my aircraft's avionics suite?
Avionics compatibility depends on your aircraft model and existing installation. The DIODE is available in: New Surplus. We recommend checking your aircraft's wiring diagrams and STC documentation, or contact our avionics team for compatibility assistance.
Does the 1n1201 come with an 8130-3 airworthiness tag?
Availability of an FAA 8130-3 tag depends on the part condition. Overhauled and repaired units typically include 8130-3 documentation. As-removed units may include a removal tag with trace history. Contact us for specific documentation on the condition you need.
Do you offer bench testing for the 1n1201?
We can arrange bench testing through our network of FAA-certified repair stations. Call (904) 998-9101 for testing availability and turnaround times, or submit an RFQ with your specific requirements.
