INSTRUMENT; CLUSTER - As Removed
P/N: 9025-3004
Category: Flight Instruments
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| As Removed | 1 Available |
Product Description
The 9025-3004 is an instrument cluster assembly that consolidates flight and engine instruments into a single panel-mounted unit. This assembly organizes primary cockpit indications—such as airspeed, altitude, attitude, and engine parameters—into a coordinated display group. The cluster streamlines wiring terminations and provides standardized mounting points for individual instruments.
Installation requires verification against the aircraft's Illustrated Parts Catalog and compliance with the applicable maintenance or avionics installation manual. Commonly used in general aviation cockpits to reduce panel complexity and improve instrument accessibility during preflight and in-flight operations.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the INSTRUMENT; CLUSTER (P/N 9025-3004)?
The 9025-3004 is an instrument cluster assembly that consolidates flight and engine instruments into a single panel-mounted unit. This assembly organizes primary cockpit indications—such as airspeed, altitude, attitude, and engine parameters—into a coordinated display group.
Is the 9025-3004 calibrated and ready to install?
Calibration status depends on the condition. Overhauled instruments come fully calibrated with an 8130-3 tag. The INSTRUMENT; CLUSTER is available in: As Removed. Contact us to confirm calibration status for your selected condition.
Can the 9025-3004 be used as a direct replacement in my aircraft?
The INSTRUMENT; CLUSTER is designed as a form-fit-function replacement. Verify the part number against your aircraft's Illustrated Parts Catalog (IPC) and instrument panel layout to confirm compatibility before ordering.
Do you offer instrument exchange programs for the 9025-3004?
Yes, we offer core exchange programs on select instruments. Send your unserviceable unit and receive a discount on the replacement. Call (904) 998-9101 or submit an RFQ to check exchange availability for the 9025-3004.
