CIRCUIT BREAKER (P/N 930023-309) - As Removed
P/N: 930023-309
Category: Circuit Breakers & Fuses
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| As Removed | 1 Available |
Product Description
The 930023-309 is a panel-mounted circuit breaker for aircraft electrical system protection. This push-to-reset/pull-to-trip breaker guards individual circuits against overcurrent conditions in 28 VDC and 115 VAC systems. Temperature-compensated design maintains consistent trip characteristics across cockpit environmental conditions.
Installed directly in aircraft breaker panels, it requires amperage selection and trip settings matched to specific circuit loads per the aircraft maintenance manual and illustrated parts catalog. Terminal torque specifications must follow OEM documentation during installation.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the CIRCUIT BREAKER (P/N 930023-309)?
The 930023-309 is a panel-mounted circuit breaker for aircraft electrical system protection. This push-to-reset/pull-to-trip breaker guards individual circuits against overcurrent conditions in 28 VDC and 115 VAC systems.
Is the 930023-309 compatible with my aircraft's avionics suite?
Avionics compatibility depends on your aircraft model and existing installation. The CIRCUIT BREAKER is available in: As Removed. We recommend checking your aircraft's wiring diagrams and STC documentation, or contact our avionics team for compatibility assistance.
Does the 930023-309 come with an 8130-3 airworthiness tag?
Availability of an FAA 8130-3 tag depends on the part condition. Overhauled and repaired units typically include 8130-3 documentation. As-removed units may include a removal tag with trace history. Contact us for specific documentation on the condition you need.
Do you offer bench testing for the 930023-309?
We can arrange bench testing through our network of FAA-certified repair stations. Call (904) 998-9101 for testing availability and turnaround times, or submit an RFQ with your specific requirements.
