NUT PLATE (P/N a1786-8z1d) - New Surplus

The a1786-8z1d is a U-type sheet spring nut plate (Tinnerman clip) that provides captive threading on sheet metal edges for #8 screws. This steel fastener clips over a sheet edge without requiring backside access, allowing secure attachment of access panels and covers in confined spaces. Conforms to NAS395 aerospace hardware standards.

Installation involves positioning the nut plate over the sheet edge and fastening with a matching #8 screw. Verify size and specification in your aircraft Illustrated Parts Catalog before installation.

What is the NUT PLATE (P/N a1786-8z1d)?

The a1786-8z1d is a U-type sheet spring nut plate (Tinnerman clip) that provides captive threading on sheet metal edges for #8 screws. This steel fastener clips over a sheet edge without requiring backside access, allowing secure attachment of access panels and covers in confined spaces.

Does the a1786-8z1d meet AN/MS/NAS aviation specifications?

Aircraft hardware is manufactured to military and aviation specifications. The NUT PLATE conforms to its applicable AN (Air Force-Navy), MS (Military Standard), or NAS (National Aerospace Standard) specification. Contact us for specific specification details.

What material is the a1786-8z1d manufactured from?

Aviation hardware is available in various materials including cadmium-plated steel, stainless steel, aluminum alloy, and titanium depending on the application. Contact us for material certification and specifications for the a1786-8z1d.

Can I order the a1786-8z1d in custom quantities?

Yes, we sell hardware in various quantities from single units to bulk lots. The NUT PLATE is available in: New Surplus. Submit an RFQ for volume pricing or call (904) 998-9101 for quantity availability.
