ADAPTER,STRAIGHT,PIPE TO (P/N an816-3) - New Surplus
P/N: an816-3
Category: Fittings & Adapters
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| New Surplus | 1 Available |
Product Description
The AN816-3 is a straight pipe-to-flared-tube adapter conforming to AN816 (SAE AS4842) specifications with a 37° flare seat. This brass fitting transitions flared tube assemblies to threaded pipe ports in aircraft hydraulic and fuel system plumbing. The adapter connects a tapped pipe port to a flared tube run, requiring an AN818 nut and AN819 sleeve for installation per aircraft maintenance manual procedures.
Standard component in fluid system repairs and new installations on general and corporate aircraft.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the ADAPTER,STRAIGHT,PIPE TO (P/N an816-3)?
The AN816-3 is a straight pipe-to-flared-tube adapter conforming to AN816 (SAE AS4842) specifications with a 37° flare seat. This brass fitting transitions flared tube assemblies to threaded pipe ports in aircraft hydraulic and fuel system plumbing.
Does the an816-3 meet AN/MS/NAS aviation specifications?
Aircraft hardware is manufactured to military and aviation specifications. The ADAPTER,STRAIGHT,PIPE TO conforms to its applicable AN (Air Force-Navy), MS (Military Standard), or NAS (National Aerospace Standard) specification. Contact us for specific specification details.
What material is the an816-3 manufactured from?
Aviation hardware is available in various materials including cadmium-plated steel, stainless steel, aluminum alloy, and titanium depending on the application. Contact us for material certification and specifications for the an816-3.
Can I order the an816-3 in custom quantities?
Yes, we sell hardware in various quantities from single units to bulk lots. The ADAPTER,STRAIGHT,PIPE TO is available in: New Surplus. Submit an RFQ for volume pricing or call (904) 998-9101 for quantity availability.
