ELBOW 9 (P/N an916-3d) - New Surplus
P/N: an916-3d
Category: Fittings & Adapters
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| New Surplus | 3 Available |
Product Description
The AN916-3D is a 90-degree elbow fitting with internal pipe threads, sized for 3/8-inch NPT connections. This AN-standard component joins two pipe-threaded ports at right angles in aircraft hydraulic, fuel, and pneumatic systems. Constructed from corrosion-resistant steel, the fitting routes fluid lines around structural obstacles and engine components in confined spaces.
Install per aircraft maintenance manual specifications, applying appropriate torque to ensure leak-free seals. Complies with SAE AS4842 standards for internal-thread elbows.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the ELBOW 9 (P/N an916-3d)?
The AN916-3D is a 90-degree elbow fitting with internal pipe threads, sized for 3/8-inch NPT connections. This AN-standard component joins two pipe-threaded ports at right angles in aircraft hydraulic, fuel, and pneumatic systems.
Does the an916-3d meet AN/MS/NAS aviation specifications?
Aircraft hardware is manufactured to military and aviation specifications. The ELBOW 9 conforms to its applicable AN (Air Force-Navy), MS (Military Standard), or NAS (National Aerospace Standard) specification. Contact us for specific specification details.
What material is the an916-3d manufactured from?
Aviation hardware is available in various materials including cadmium-plated steel, stainless steel, aluminum alloy, and titanium depending on the application. Contact us for material certification and specifications for the an916-3d.
Can I order the an916-3d in custom quantities?
Yes, we sell hardware in various quantities from single units to bulk lots. The ELBOW 9 is available in: New Surplus. Submit an RFQ for volume pricing or call (904) 998-9101 for quantity availability.
