SLEEVE (P/N ms20819-5d) - New Surplus, As Removed
P/N: ms20819-5d
Category: Fasteners & Hardware
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| New Surplus | 26 Available |
| As Removed | 2 Available |
Product Description
The MS20819-5D is an aluminum tube fitting sleeve designed for 5/16-inch flared tubing in aircraft hydraulic and fluid line systems. This sleeve backs the tube flare and distributes load from the connecting nut, preventing damage to the flare cone. It installs behind the flare on 37-degree flared connections paired with AN818 nuts.
Constructed per MS20819 specifications and commonly cross-referenced with AN819/SAE AS5176, the sleeve ensures reliable sealed connections in pressurized aircraft systems. Torque the nut to values specified in the applicable aircraft maintenance manual.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the SLEEVE (P/N ms20819-5d)?
The MS20819-5D is an aluminum tube fitting sleeve designed for 5/16-inch flared tubing in aircraft hydraulic and fluid line systems. This sleeve backs the tube flare and distributes load from the connecting nut, preventing damage to the flare cone.
Does the ms20819-5d meet AN/MS/NAS aviation specifications?
Aircraft hardware is manufactured to military and aviation specifications. The SLEEVE conforms to its applicable AN (Air Force-Navy), MS (Military Standard), or NAS (National Aerospace Standard) specification. Contact us for specific specification details.
What material is the ms20819-5d manufactured from?
Aviation hardware is available in various materials including cadmium-plated steel, stainless steel, aluminum alloy, and titanium depending on the application. Contact us for material certification and specifications for the ms20819-5d.
Can I order the ms20819-5d in custom quantities?
Yes, we sell hardware in various quantities from single units to bulk lots. The SLEEVE is available in: New Surplus, As Removed. Submit an RFQ for volume pricing or call (904) 998-9101 for quantity availability.
