ELBOW,PIPE TO TUBE (P/N ms20822-4) - New Surplus
P/N: ms20822-4
Category: Fittings & Adapters
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| New Surplus | 4 Available |
Product Description
The MS20822-4 is a 90-degree elbow fitting that connects 1/4 inch tubing to 1/8 inch pipe in aircraft hydraulic systems. This military standard component features a 37° flared tube end and male pipe thread interface. The fitting directs fluid flow at a right angle while transitioning between different line sizes and connection types.
Install with proper tube flare preparation and thread torque per maintenance manual specifications to ensure leak-free operation under system pressure.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the ELBOW,PIPE TO TUBE (P/N ms20822-4)?
The MS20822-4 is a 90-degree elbow fitting that connects 1/4 inch tubing to 1/8 inch pipe in aircraft hydraulic systems. This military standard component features a 37° flared tube end and male pipe thread interface.
Does the ms20822-4 meet AN/MS/NAS aviation specifications?
Aircraft hardware is manufactured to military and aviation specifications. The ELBOW,PIPE TO TUBE conforms to its applicable AN (Air Force-Navy), MS (Military Standard), or NAS (National Aerospace Standard) specification. Contact us for specific specification details.
What material is the ms20822-4 manufactured from?
Aviation hardware is available in various materials including cadmium-plated steel, stainless steel, aluminum alloy, and titanium depending on the application. Contact us for material certification and specifications for the ms20822-4.
Can I order the ms20822-4 in custom quantities?
Yes, we sell hardware in various quantities from single units to bulk lots. The ELBOW,PIPE TO TUBE is available in: New Surplus. Submit an RFQ for volume pricing or call (904) 998-9101 for quantity availability.
