CIRCUIT BREAKER (P/N w23-x1a1g-10) - New Surplus, As Removed
P/N: w23-x1a1g-10
Category: Circuit Breakers & Fuses
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| New Surplus | 2 Available |
| As Removed | 1 Available |
Product Description
The w23-x1a1g-10 is a TE Connectivity Potter & Brumfield thermal circuit breaker rated 10 amperes at 240 VAC/50 VDC. This push-pull actuated breaker protects aircraft electrical feeders and avionics loads on 14/28 VDC buses from overcurrent conditions. The unit mounts through a threaded bushing with screw terminal connections, following standard aerospace panel installation practices.
Thermal-trip protection automatically disconnects power when current exceeds the 10 A rating, preventing damage to connected equipment and wiring. Installation requires wiring per aircraft electrical schematics and FAA AC 43.13-1B guidance for circuit protection devices.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the CIRCUIT BREAKER (P/N w23-x1a1g-10)?
The w23-x1a1g-10 is a TE Connectivity Potter & Brumfield thermal circuit breaker rated 10 amperes at 240 VAC/50 VDC. This push-pull actuated breaker protects aircraft electrical feeders and avionics loads on 14/28 VDC buses from overcurrent conditions.
Is the w23-x1a1g-10 compatible with my aircraft's avionics suite?
Avionics compatibility depends on your aircraft model and existing installation. The CIRCUIT BREAKER is available in: New Surplus, As Removed. We recommend checking your aircraft's wiring diagrams and STC documentation, or contact our avionics team for compatibility assistance.
Does the w23-x1a1g-10 come with an 8130-3 airworthiness tag?
Availability of an FAA 8130-3 tag depends on the part condition. Overhauled and repaired units typically include 8130-3 documentation. As-removed units may include a removal tag with trace history. Contact us for specific documentation on the condition you need.
Do you offer bench testing for the w23-x1a1g-10?
We can arrange bench testing through our network of FAA-certified repair stations. Call (904) 998-9101 for testing availability and turnaround times, or submit an RFQ with your specific requirements.
