SWITCH (P/N w31-x2m1g-20) - As Removed
P/N: w31-x2m1g-20
Category: Switches
This product requires a custom quote. Please contact our sales team for pricing information or submit an RFQ (Request for Quote).
Available Inventory
| Condition | Stock |
|---|---|
| As Removed | 3 Available |
Product Description
The W31-X2M1G-20 is a 20-ampere thermal circuit breaker for aircraft electrical panels. This single-pole toggle switch provides resettable overcurrent protection with trip-free operation, preventing nuisance shutdowns on avionics and cockpit branch circuits. The breaker features screw-terminal connections and mounts through a threaded bushing for secure panel installation.
TE Connectivity's W31 series design handles thermal cycling and vibration typical in flight operations. Installation requires torquing per the aircraft wiring manual specifications.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the SWITCH (P/N w31-x2m1g-20)?
The W31-X2M1G-20 is a 20-ampere thermal circuit breaker for aircraft electrical panels. This single-pole toggle switch provides resettable overcurrent protection with trip-free operation, preventing nuisance shutdowns on avionics and cockpit branch circuits.
Is the w31-x2m1g-20 compatible with my aircraft's avionics suite?
Avionics compatibility depends on your aircraft model and existing installation. The SWITCH is available in: As Removed. We recommend checking your aircraft's wiring diagrams and STC documentation, or contact our avionics team for compatibility assistance.
Does the w31-x2m1g-20 come with an 8130-3 airworthiness tag?
Availability of an FAA 8130-3 tag depends on the part condition. Overhauled and repaired units typically include 8130-3 documentation. As-removed units may include a removal tag with trace history. Contact us for specific documentation on the condition you need.
Do you offer bench testing for the w31-x2m1g-20?
We can arrange bench testing through our network of FAA-certified repair stations. Call (904) 998-9101 for testing availability and turnaround times, or submit an RFQ with your specific requirements.
