WEAR PAD: BRAKE,ASSEMBLY (P/N 109-01500) - New Surplus
P/N: 109-01500
Category: Brakes
Flat-rate shipping. Choose Ground or a faster service at checkout.
Flat-rate shipping covers most parts. If your order turns out to need freight or special handling, we'll contact you with the updated shipping cost before it ships. You can pay the difference or cancel for a full refund. International buyers pay any duties and import taxes.
Available Inventory
| Condition | Price | Stock |
|---|---|---|
| New Surplus | $20.00 | 151 Available |
Product Description
The 109-01500 is a metallic friction brake wear pad assembly for 8-inch internal, single-cylinder, six-piston aircraft wheel brakes. This pad provides the friction lining surface that contacts the rotor during braking, restoring stopping performance as wear occurs. The metallic composition withstands repeated thermal cycling and high-energy stops common in aircraft operations.
Designed for Socata TBM 700/850 brake systems, the pad installs during scheduled maintenance to maintain proper torque-tube and rotor interface geometry. Replace per aircraft maintenance manual specifications to ensure consistent braking response.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the WEAR PAD: BRAKE,ASSEMBLY (P/N 109-01500)?
The 109-01500 is a metallic friction brake wear pad assembly for 8-inch internal, single-cylinder, six-piston aircraft wheel brakes. This pad provides the friction lining surface that contacts the rotor during braking, restoring stopping performance as wear occurs.
What aircraft models does the 109-01500 fit?
Part number 109-01500 is listed in multiple aircraft Illustrated Parts Catalogs. Always verify the WEAR PAD: BRAKE,ASSEMBLY against your specific aircraft model's IPC and Type Certificate Data Sheet before ordering. Currently available in: New Surplus.
Does the 109-01500 include an 8130-3 tag and maintenance records?
Documentation varies by condition. Overhauled and repaired landing gear components include 8130-3 airworthiness tags. New surplus includes manufacturer documentation. Contact us for trace documentation on the specific condition you need.
Do you offer volume pricing for fleet orders of the 109-01500?
Yes, we offer quantity discounts for fleet maintenance orders. Submit a Request for Quote (RFQ) specifying your required quantity, or call (904) 998-9101 to discuss fleet pricing for the WEAR PAD: BRAKE,ASSEMBLY.
