ELBOW AN823-4 (P/N an823-4) - New Surplus
P/N: an823-4
Category: Fittings & Adapters
Flat-rate shipping. Choose Ground or a faster service at checkout.
Flat-rate shipping covers most parts. If your order turns out to need freight or special handling, we'll contact you with the updated shipping cost before it ships. You can pay the difference or cancel for a full refund. International buyers pay any duties and import taxes.
Available Inventory
| Condition | Price | Stock |
|---|---|---|
| New Surplus | $12.00 | 10 Available |
Product Description
The AN823-4 is a 45-degree flared tube elbow connecting 1/4-inch 37° flared tubing to 1/8 NPT ports in aircraft fluid systems. This brass fitting adapts between flare and pipe thread standards, enabling directional changes in fuel, hydraulic, and oil lines. Installation requires mating the flared tube end with the elbow's flare seat and threading the NPT port into the system component.
Torque and thread-sealing compound follow aircraft maintenance manual specifications. The 45-degree angle allows compact routing in confined engine bay and fuselage spaces.
Please note: Product descriptions are provided for informational purposes. Always refer to your aircraft's Illustrated Parts Catalog (IPC) to verify part compatibility and specifications.
Frequently Asked Questions
What is the ELBOW AN823-4 (P/N an823-4)?
The AN823-4 is a 45-degree flared tube elbow connecting 1/4-inch 37° flared tubing to 1/8 NPT ports in aircraft fluid systems. This brass fitting adapts between flare and pipe thread standards, enabling directional changes in fuel, hydraulic, and oil lines.
Does the an823-4 meet AN/MS/NAS aviation specifications?
Aircraft hardware is manufactured to military and aviation specifications. The ELBOW AN823-4 conforms to its applicable AN (Air Force-Navy), MS (Military Standard), or NAS (National Aerospace Standard) specification. Contact us for specific specification details.
What material is the an823-4 manufactured from?
Aviation hardware is available in various materials including cadmium-plated steel, stainless steel, aluminum alloy, and titanium depending on the application. Contact us for material certification and specifications for the an823-4.
Can I order the an823-4 in custom quantities?
Yes, we sell hardware in various quantities from single units to bulk lots. The ELBOW AN823-4 is available in: New Surplus. Submit an RFQ for volume pricing or call (904) 998-9101 for quantity availability.
